RCS-090-ER8
Precision ER8 Collet Rotary Stage with Pneumatic Collet Actuation
- Product SKU:
- RCS-090-ER8
Do you have questions? Contact our Experts: (866) 906-2709
Overview
The RCS-090 is a compact, high-precision rotary stage engineered for laser tube processing applications where space is at a premium. It features an integrated ER8 collet system with automatic gripping and adjustable clamping force to accommodate small-diameter parts across a range of materials and wall thicknesses. Its direct-drive rotary architecture delivers smooth, accurate, near zero-backlash motion for demanding cutting and welding operations. Contact us to learn how the RCS-090 can integrate into your laser processing system.
Features
• Continuous 360° rotation
• High resolution encoder
• Brushless DC motor
• Ø 5.00mm through bore
• Spring-close, air-open collet
• Accepts ER8 type collets
Specifications
| Accuracy: | ±30 arc-sec |
|---|---|
| Bi-Directional Repeatability: | 4.0 arc-sec |
| Axial Runout: | 30 µm |
| Radial Runout: | 30 µm |
| Stage Mass: | 1.5 kg |
| Maximum Velocity: | 600 rpm |
Mechanical Details
